45INTELLIPANEL(TM) CONTROL
C Setting the ride control
Touch the left half of the ride control switch (7), and the
ride control gets activated. A touch on the right half
deactivates it.
The ride control unit serves to absorb vibrations and
shocks upon the tractor, when the machine is moved
equipped with a 3-point-hitched implement.
(The ride control unit activates itself if the 3-P. quick raise
switch is pressed to bring the rear hitch up to its top limit
and the traveling speed rises above 6 km/h (3.7 mph).)
C Setting the wheel slip control (9)
Used together with the optional radar device, the tractor
can be constantly kept under the best control. This helps
to improve your productivity. (For details, contact your
local KUBOTA Dealer.)
C 3-Point hitch status indicator (2)
The control status of the 3-point hitch is displayed all the
time with the following indicators.
(1) Blocked (Neutral)
(2) Float
(3) Transport
(4) Work
