17
03-M-E3B, 03-M-DI-E3B, 03-M-E3BG WSM
DIMENSIONS
W1028881
V2003-M V2203-M V2403-M V2403-M-T
A 652.0 mm (25.67 in.) 652.0 mm (25.67 in.) 652.0 mm (25.67 in.) 667.1 mm (26.26 in.)
B 480.0 mm (18.90 in.) 480.0 mm (18.90 in.) 480.0 mm (18.90 in.) 449.0 mm (17.68 in.)
C 643.0 mm (25.31 in.) 643.0 mm (25.31 in.) 648.0 mm (25.51 in.) 737.3 mm (29.03 in.)
KiSC issued 07, 2008 A
