22
03-M-E3B, 03-M-DI-E3B, 03-M-E3BG WSM
WIRING DIAGRAM
WIRING DIAGRAM
3EEADAHFP001A
Alternator
Starter
ST
B
Battery
Slow Blow Fuse
3.0
Key Switch
30 AC 50 19
AC
OFF
ON
Glow
Start
Glow Relay
4
3
2
1
Glow Plug
Hour Meter
Pilot Lamp
12V3.4W X 4
WT
OP
ALT
Glow
(Water Temperature)
(Oil Pressure)
(Alternator)
(Glow Plug)
Engine Speed Sensor
Water Temp. Sensor
Oil Switch
Water Temp. Switch
Slowdown(1200 min
-1
(rpm))
Speed Switch
(1800 min
-1
(rpm)/1500 min
-1
(rpm))
Manual Stop Switch
(Run/Stop)
Solenoid
ECU (Electronic Control Unit)
Start Relay
2
4
1
3
1.25
1.25
0.85
3.0
3.0
5A 5A
5A
10A
10A
3.0
0.85 0.85
3.0
B
IG
L
1.25
26
18
10
12
11
19
34
5
12
13
14
20
21
22
6
7
8
9
15
16 17
23
24 25
34
3.03.0
( 50 A )
KiSC issued 07, 2008 A
