CYLINDER HEAD
REMOVAL 〈 SH10BA〉
Remove the rear carrier.
Remove the frame body cover. (
2-5)
Remove the spark plug cap.
Remove the three bolts attaching the fan
cover to remove the fan cover.
Remove the two joint lock nuts on the front
of the exhaust muffler and then remove the
two exhaust muffler lock bolts.
Remove the bolt attaching the engine hood
to remove the engine hood.
The installation sequence is the reverse of
removal.
Remove the spark plug.
Remove the cylinder head bolts and the
cylinder head.
Remove the cylinder head gasket.
When installing the exhaust muffler,
first tighten the two nuts on the front
and then tighten the two bolts.
