KYMCO Mini LS - Page 71

Work Shop use only-- Replacing the ECU(2)
70
 Switch the Scooter off.
 remove ECU protect cover
 Disassemble the battery plugs (+)(-)and (1)(2) as picture--
 Disassemble the ECU’s plug as picture--
 Remove ECU bolts --.
 Disassemble the ECU--.
 Installation is in the reverse order of removal.




