Work Shop use only- Removing and installing the

motor

 Switch the Scooter off.

 Removing the seat.

 Removing the batteries case .

 Removing drive unit as picture.--

 Remove the rear wheels.

 Remove the motor stay bolts as picture.--

 Disassemble the electric motor.




