Work Shop use only-Adjusting the TOE-IN(1)

Step 1: Handlebar

- Push the tiller backward into the required position.

- Moving the handlebar to the seat as picture

- Ensure the handlebar is fixed firmly by seat. If the

throttle levers touch the seat, remove the throttle levers.
