6. ENGINE REMOVAL
6-12
MXU 300/ 250
Remove the four bolts for remove the left
and right engine brackets.
Remove the rear upper mounting bolt and
nut.
Remove the rear lower mounting bolt and
nut.
Brackets
Bolts
Nut Bol
t
Bolt Nu
t
