9.DRIVE AND DRIVEN PULLEYS
9-9
MXU 300/250
Loosen the clutch spring compressor and
disassemble the clutch/driven pulley assembly.
Remove the seal collar.
Pull out the guide roller pins and guide rollers.
Remove the movable driven face from the
driven face.
Remove the oil seal from the movable driven
face.
Movable Driven Face
Guide Roller Pin
O-ring
Oil Seal
