10.FINAL REDUCTION/
TRANSMISSION SYSTEM
10-22
MXU 300/250
Remove the two bolts and driveshaft bearing
set plate.
Remove the countershaft bearing and
driveshaft bearing with special tools.
Special tools:
Bearing puller E037
Bearing/Oil seal install E014
Install a new driveshaft bearing and a new
countershaft bearing with special tool.
Special tools:
Bearing/Oil seal install E014
Install the bearing set plate.
Install and tighten the two new bolts (replace
the new bolts).
Bolts
Set Plate
Countershaft Bearing
Driveshaft Bearing
Countershaft Bearing
Driveshaft Bearing
To Next Page
