10.FINAL REDUCTION/
TRANSMISSION SYSTEM
10-24
MXU 300/250
Install a new inner bearing with the special
tool.
Special tools:
Bearing/Oil seal install E014
Install a new outer bearing with special tool.
Special tools:
Bearing/Oil seal install E014
Apply the oil to a new oil seal lip and then
install the oil seal with the special tool.
Special tools:
Bearing/Oil seal install E014
Oil Seal
Inner Bearing Snap Ring
Outer Bearing Snap Ring
To Next Page
