10.FINAL REDUCTION/
TRANSMISSION SYSTEM
10-27
MXU 300/250
Install the gasket and transmission case
cover.
Install and tighten the bolts to the specified
torque.
Torque: 2.7 kgf-m (27 Nm, 20 lbf-ft)
Install the shim and drive bevel gear.
Hold the clutch out and tighten the drive
bevel gear nut to the specified torque.
Torque: 100 N-m (10 kgf-m, 72.5 lb-ft)
Stake the nut with a center punch.
Transmission Cover/Gaske
To Next Page
