7-13
Document Box > Functions for Document Box
JPEG/TIFF Print
Select the image size when printing JPEG or TIFF files.
1
Display the screen.
1 Referring to Printing Documents Stored in Removable USB Memory on page 7-3, display
the screen.
2
2
Select the function.
Paper Size Fit the image size to the selected paper size.
Image Resolution Print at resolution of the actual image.
Print Resolution Fit the image size to the print resolution.
Ready to print from Box.
Functions
Encrypted PDF Password
Off
Close
10:10
JPEG/TIFF Print
Paper Size
Off
XPS Fit to Page
2/2
Add/Edit
Shortcut
Ready to print from Box.
Print Copies
Paper
Selection
Collate/
Offset
Duplex
A4
Functions
10:10
Cancel
Collate 1-sided
1
2
Use [ ] or [ ] to scroll up and down.
GB0097_00 GB0099_01
GB0101_00
Ready to print from Box.
JPEG/TIFF Print
Paper Size Image Resolution Print Resolution
10:10
Cancel OK

Kyocera ECOSYS FS-C8520MFP Specifications

General

Category	Printer
Type	Multifunction Printer
Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Speed (B/W)	20 ppm
Print Speed (Color)	20 ppm
Max Print Speed (B/W)	20 ppm
Max Print Speed (Color)	20 ppm
Print Resolution	600 x 600 dpi
Max Print Resolution	9600 x 600 dpi
Max Paper Size	A3
Duplex Printing	Yes
Scanner Type	Flatbed, ADF
Scan Resolution	600 x 600 dpi
Duplex Scanning	Yes
Copy Resolution	600 x 600 dpi
Fax	Yes
Supported Paper Sizes	A3, A4, A5, A6, B5, Letter, Legal
Monthly Duty Cycle	65000 pages
Max Paper Capacity	1600 sheets
Memory	1 GB
Connectivity	USB, Ethernet
Copier Speed (B/W)	20 ppm
Copier Speed (Color)	20 ppm
Copy Speed (B/W)	20 ppm
Copy Speed (Color)	20 ppm
Display	4.3-inch touch screen
