Kyocera ECOSYS M4132idn User Guide

Installation
User Guide1-3
5
Click OK.
Note: If you entered a different Read community name, the Devices list is
cleared. Click the Refresh icon to rediscover devices.
Data Collection
With this feature, you can help improve printer driver software by choosing to
participate in anonymous Data Collection. You can make this selection during
driver installation or from the Kyocera logo's About dialog box, located at the
bottom of Device Settings and the Printing Preferences dialog box.
Express Install
Express Install refers to quick device, driver, and utility installation for a USB or
network connection in Windows operating systems. The installation application
discovers printing devices that are turned on, and connected by USB or network
cable. One or more feature packages can be installed together.
If the installer cannot find your printing system, contact your system
administrator.
Note: You must install .NET Framework 4.0 or later to use Status Monitor.
Installing with Express Install
1
Ensure that your printing system and computer are turned on and connected by
USB or network cable.
2
In Express Install, the installer looks for your printing system. Each discovered
device is displayed in the device list as an icon with a model name and port
name.
If your device is discovered, select your model in the device list.
If discovery does not find your device, remove and reinsert the USB or network
cable, and ensure that it is connected properly. Click the Refresh icon to
rediscover devices.
3
You can also find a device by typing a partial or full search term in the search
text box above the device list. You can search the discovered devices by model
name, IP address, host name, or USB port. The results are displayed in the
device list. If the search finds your device, select it. Click the x icon to clear the
text box, and return to the list of all discovered devices.
4
You can select Use host name as port name to use a host name for the
Standard TCP/IP port. (Not available with a USB connection.)
5
The installer automatically selects all the features in the feature list. You can
select or clear any check box for individual features.
6
Review your settings. At least one device and one feature must be selected to
enable the Install button. If your settings are correct, click Install.

Kyocera ECOSYS M4132idn Specifications

General

N-up printing	2, 4
Secure printing	Yes
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto/Manual
Time to first page (black, normal)	5.2 s
Print speed (black, normal quality, A3)	17 ppm
Print speed (black, normal quality, A4/US Letter)	32 ppm
Duplex print speed (black, normal quality, A4/US Letter)	29 ppm
Copier resize	25 - 400 %
Duplex copying mode	Auto
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A3)	17 cpm
Copy speed (black, normal quality, A4)	32 cpm
Scan to	E-mail, FTP, SMB, TWAIN, USB, WIA
Scan drivers	TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Maximum scan area	297 x 420 mm
Scan speed (color)	50 ppm
Image formats supported	JPG, MMR, TIF
Document formats supported	PDF, XPS
Faxing	No
Fax memory	700 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	400 x 400 DPI
Fax transmission speed	3 sec/page
Printing colors	Black
Duplex functions	Copy, Fax, Print, Scan
Stapling capacity	50 sheets
Maximum duty cycle	100000 pages per month
Recommended duty cycle	5000 - 10000 pages per month
Replacement cartridges	TK-6115 (15.000 pagina's)
Number of print cartridges	1
Page description languages	Microsoft XPS, OpenXPS, PCL 5e, PCL 6, PCL XL, PostScript 3
Processor cores	2
Processor family	ARM Cortex-A9
Card reader integrated	-
Compatible memory cards	SD
Maximum internal memory	3000 MB
Sound power level (standby)	34 dB
Sound pressure level (copying)	50 dB
Paper input type	Cassette, Paper tray
Total input capacity	500 sheets
Total output capacity	300 sheets
Maximum input capacity	1600 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Custom media width	98 - 297 mm
Maximum print size	297 x 432 mm
Custom media length	148 - 432 mm
Media thickness (min)	0.11 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Folio (media size), Ledger (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Multi-purpose tray media types	Legal, Letter, Plain paper
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	45 - 256 g/m²
Auto Document Feeder (ADF) media weight	45 - 160 g/m²
Display	TFT
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (ready)	70 W
Power consumption (sleep)	0.5 W
Power consumption (PowerSave)	45 W
Power consumption (average operating)	490 W
Energy Star Typical Electricity Consumption (TEC)	1.39 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Certification	TÜV/GS, CE
Cables included	AC
Included cartridge capacity (black)	3000 pages
Operating altitude	0 - 3500 m
Non-operating altitude	0.6 - 15000 m
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	Blue Angel, REACH, RoHS, EPEAT Silver, ENERGY STAR
Package width	760 mm
Package height	911 mm
Package weight	74000 g
Harmonized System (HS) code	84433100

Weight and Dimensions

Width	590 mm
Height	688 mm
