Kyocera ECOSYS M4132idn User Guide

User Guide1-1
1 Installation
A printer driver is an application that manages communication between a printer
and your computer.
Once installed, the printer driver settings must be configured in the printer
Properties and Printing Preferences.
In the Product Library window, there are two methods of installation. Express
Install is a quick way to install a driver and certain features in package form.
With Custom Install, you select from individual drivers and utilities.
With Upgrade, you can update the driver and utilities to a newer version. This
feature is only available if there is a product that needs to be upgraded. In a
client/server environment, you cannot upgrade older drivers. Contact your
printing system dealer for more information.
With Maintenance, you can run certain utilities. You can access release notes,
the printing system operation guide, and other materials by selecting
Documents. With Uninstall, you can remove drivers and utilities.
Note: In Windows operating systems, you must be logged in with
administrator rights to install the printer driver.
The Driver
In Windows 10, Windows Server 2016, Windows 8.1, Windows Server 2012 R2,
Windows 8, Windows Server 2012, Windows 7, Windows Server 2008 R2,
Windows Vista, and Windows Server 2008 with a USB connection, you can
install a driver from the Microsoft Windows Update site if a certified driver is
available and the system is connected to the web.
We recommend you continue to install the driver from the supplied installation
disk for an expanded feature set. In Windows, if the Found New Hardware
Wizard dialog box appears during the installation process, click Cancel. If the
Hardware Installation warning dialog box appears, click Continue Anyway.
Preparing to Install the Driver
1
Turn on the computer and the printer.
2
Insert the Product Library disk into the disk drive. The application should start
automatically.
Note: If the Product Library fails to start after inserting it into the disk drive,
use Windows Explorer to locate Setup.exe on the local drive and double-click
to open.
3
To proceed, read and accept the license agreement that appears.

Kyocera ECOSYS M4132idn Specifications

General

N-up printing	2, 4
Secure printing	Yes
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto/Manual
Time to first page (black, normal)	5.2 s
Print speed (black, normal quality, A3)	17 ppm
Print speed (black, normal quality, A4/US Letter)	32 ppm
Duplex print speed (black, normal quality, A4/US Letter)	29 ppm
Copier resize	25 - 400 %
Duplex copying mode	Auto
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A3)	17 cpm
Copy speed (black, normal quality, A4)	32 cpm
Scan to	E-mail, FTP, SMB, TWAIN, USB, WIA
Scan drivers	TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Maximum scan area	297 x 420 mm
Scan speed (color)	50 ppm
Image formats supported	JPG, MMR, TIF
Document formats supported	PDF, XPS
Faxing	No
Fax memory	700 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	400 x 400 DPI
Fax transmission speed	3 sec/page
Printing colors	Black
Duplex functions	Copy, Fax, Print, Scan
Stapling capacity	50 sheets
Maximum duty cycle	100000 pages per month
Recommended duty cycle	5000 - 10000 pages per month
Replacement cartridges	TK-6115 (15.000 pagina's)
Number of print cartridges	1
Page description languages	Microsoft XPS, OpenXPS, PCL 5e, PCL 6, PCL XL, PostScript 3
Processor cores	2
Processor family	ARM Cortex-A9
Card reader integrated	-
Compatible memory cards	SD
Maximum internal memory	3000 MB
Sound power level (standby)	34 dB
Sound pressure level (copying)	50 dB
Paper input type	Cassette, Paper tray
Total input capacity	500 sheets
Total output capacity	300 sheets
Maximum input capacity	1600 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Custom media width	98 - 297 mm
Maximum print size	297 x 432 mm
Custom media length	148 - 432 mm
Media thickness (min)	0.11 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Folio (media size), Ledger (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Multi-purpose tray media types	Legal, Letter, Plain paper
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	45 - 256 g/m²
Auto Document Feeder (ADF) media weight	45 - 160 g/m²
Display	TFT
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (ready)	70 W
Power consumption (sleep)	0.5 W
Power consumption (PowerSave)	45 W
Power consumption (average operating)	490 W
Energy Star Typical Electricity Consumption (TEC)	1.39 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Certification	TÜV/GS, CE
Cables included	AC
Included cartridge capacity (black)	3000 pages
Operating altitude	0 - 3500 m
Non-operating altitude	0.6 - 15000 m
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	Blue Angel, REACH, RoHS, EPEAT Silver, ENERGY STAR
Package width	760 mm
Package height	911 mm
Package weight	74000 g
Harmonized System (HS) code	84433100

Weight and Dimensions

Width	590 mm
Height	688 mm
