Kyocera ECOSYS M4132idn User Guide

Device Settings
Printer Driver 3-3
Select to let the driver check the printing system at every occurrence of a
fixed time period. The driver regularly checks for any changes in optional
devices or memory.
3
Click OK in all dialog boxes.
Memory
Memory is the amount of standard and optional memory installed in the printing
system. To maximize the downloading of printing system fonts, the driver must
be set to match the total printing system memory. By default, the Memory
setting matches the standard memory in the printing system. If optional memory
is installed, set the memory in the printer driver to match the total amount of
memory.
Setting the Memory
1
Install optional DIMM memory in the printing system.
2
In Device Settings > Memory, type or select the amount of total installed
memory.
RAM Disk
The RAM disk functions as a virtual storage device, saving print requests into
the printing system’s memory. Because the RAM disk is temporary memory, all
data stored there is lost when the power is turned off. The setting for RAM disk
size must match the operation panel setting. The maximum RAM disk size
depends on the amount of installed memory.
If selected, the Ignore application collation feature in the Compatibility
Settings dialog box lets the driver control collation. RAM disk can then increase
the print speed of collated multiple copies by sending the print job just once.
Note: When a storage device is installed, the RAM disk feature is inactive.
In a client/server environment, this feature is unavailable to a client logged in as
a restricted user.
Setting RAM Disk
1
At the printing system's operation panel, turn on RAM disk and set its size.
2
In Device Settings > Device options, select RAM disk.
3
In the RAM disk text box, type or select the desired RAM disk size.
Administrator Settings
With this feature, an administrator can set options that include controlling
accessibility, displaying features in the interface and setting a password to
control access to the Administrator Settings options.
In a client/server environment, this feature is unavailable to a client logged in as
a restricted user.

Kyocera ECOSYS M4132idn Specifications

General

N-up printing	2, 4
Secure printing	Yes
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto/Manual
Time to first page (black, normal)	5.2 s
Print speed (black, normal quality, A3)	17 ppm
Print speed (black, normal quality, A4/US Letter)	32 ppm
Duplex print speed (black, normal quality, A4/US Letter)	29 ppm
Copier resize	25 - 400 %
Duplex copying mode	Auto
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A3)	17 cpm
Copy speed (black, normal quality, A4)	32 cpm
Scan to	E-mail, FTP, SMB, TWAIN, USB, WIA
Scan drivers	TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Maximum scan area	297 x 420 mm
Scan speed (color)	50 ppm
Image formats supported	JPG, MMR, TIF
Document formats supported	PDF, XPS
Faxing	No
Fax memory	700 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	400 x 400 DPI
Fax transmission speed	3 sec/page
Printing colors	Black
Duplex functions	Copy, Fax, Print, Scan
Stapling capacity	50 sheets
Maximum duty cycle	100000 pages per month
Recommended duty cycle	5000 - 10000 pages per month
Replacement cartridges	TK-6115 (15.000 pagina's)
Number of print cartridges	1
Page description languages	Microsoft XPS, OpenXPS, PCL 5e, PCL 6, PCL XL, PostScript 3
Processor cores	2
Processor family	ARM Cortex-A9
Card reader integrated	-
Compatible memory cards	SD
Maximum internal memory	3000 MB
Sound power level (standby)	34 dB
Sound pressure level (copying)	50 dB
Paper input type	Cassette, Paper tray
Total input capacity	500 sheets
Total output capacity	300 sheets
Maximum input capacity	1600 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Custom media width	98 - 297 mm
Maximum print size	297 x 432 mm
Custom media length	148 - 432 mm
Media thickness (min)	0.11 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Folio (media size), Ledger (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Multi-purpose tray media types	Legal, Letter, Plain paper
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	45 - 256 g/m²
Auto Document Feeder (ADF) media weight	45 - 160 g/m²
Display	TFT
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (ready)	70 W
Power consumption (sleep)	0.5 W
Power consumption (PowerSave)	45 W
Power consumption (average operating)	490 W
Energy Star Typical Electricity Consumption (TEC)	1.39 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Certification	TÜV/GS, CE
Cables included	AC
Included cartridge capacity (black)	3000 pages
Operating altitude	0 - 3500 m
Non-operating altitude	0.6 - 15000 m
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	Blue Angel, REACH, RoHS, EPEAT Silver, ENERGY STAR
Package width	760 mm
Package height	911 mm
Package weight	74000 g
Harmonized System (HS) code	84433100

Weight and Dimensions

Width	590 mm
Height	688 mm
