Kyocera ECOSYS P2135dn User Manual

7-26 Using the Operation Panel
Print Settings
These settings specify printing parameters such as the print quality used
for printing (Normal or Fine), the number of copies, reduced printing and
the page orientation.
The options available in Print Settings are as follows:
• Paper Source (Selecting the paper feed source)
• Auto Cass. Change (Auto Cassette Change setting)
• MP Tray Priority (The settings for priority paper feed from the MP tray)
• Paper Feed Mode (Setting the paper feed source)
• Duplex (Duplex printing)
• Override A4/LT (Overriding difference between A4 and Letter)
• Emulation (Setting the emulation)
• Font Select (Selecting the default font)
• Code Set (Setting the code set)
• Print Quality (Setting print quality)
• Page Set (Setting pagination)
• Job Name (The Job Name display settings)
1 Press [MENU].
2 Press  or  repeatedly until Print Settings > appears.
Paper Source (Selecting the paper feed source)
You can select the paper source, from which the printer feeds paper as
the default. If an optional paper feeder(s) is installed, it is also available
for the default paper source.
1 Press  while Print Settings > is displayed.
2 Press  or  repeatedly until >Paper Source appears.
3 To change the current paper feed source, press [OK]. A blinking
question mark (?) appears.
4 Press  or  to display the desired paper feed source. The message
display toggles through the following paper feed sources, depending
on the installed optional paper feeders (from the top most paper
cassette to the bottom paper cassette):
MP tray
Cassette 1
Cassette 2
Cassette 3
Cassettes 2 and 3 are available for selection when the optional
paper feeders are installed.
5 Press [OK].
6 Press [MENU]. The display returns to Ready.
Print Settings >
>Paper Source
? Cassette 1

Kyocera ECOSYS P2135dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Printing colors	Black
Maximum duty cycle	2800 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	300 sheets
Total output capacity	- sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Maximum number of input trays	4
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Processor family	PowerPC
Maximum internal memory	1280 MB
Sound power level (standby)	34.2 dB
Sound pressure level (printing)	53.5 dB
Sound pressure level (quiet mode)	50.2 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Display number of lines	2 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	11 W
Power consumption (printing)	499 W
Power consumption (PowerSave)	2.5 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	267 mm
