Kyocera ECOSYS P4040dn Service Manual

2P7/2R0/3PN
2-3-11
YC19
15 SCNT O 0/3.3 V DC Separation output control signal
Connected to
the high volt-
age PWB
16 TRREM O 0/3.3 V DC TC remote signal
17 TCNT O Analog TC control signal
18 +24V3 O 24 V DC 24 V DC power output to HVPWB
YC20
A1 +5V2 O 5 V DC 5 V DC power output to MPWB
Connected to
the main
PWB
A2 +5V2 O 5 V DC 5 V DC power output to MPWB
A3 GND - - Ground
A4 GND - - Ground
A5 VBUS I 3.3 V DC 3.3 V DC power output to USB host
A6 GND - - Ground
A7 C2P_BUZCO
N
I 0/3.3 V DC Buzzer control signal
A8 C2P_LCDCO
N
I 0/3.3 V DC LCD: On/Off
A9 C2P_SDAT I 0/3.3 V DC The data signal between panel main
A10 SAMPLE1 I 0/3.3 V DC Sample / hold signal 1
A11 GND - - Ground
A12 VDATA2P I LVDS Video data 2 signal (+)
A13 VDATA2N I LVDS Video data 2 signal (-)
A14 GND - - Ground
A15 E2C_IRN O 0/3.3 V DC Engine interrupt signal
A16 C2E_SDAT I 0/3.3 V DC Serial communication data input
A17 E2C_SBSY O 0/3.3 V DC System busy signal
A18 GND - - Ground
A19 GND - - Ground
A20 E2C_INT O 0/3.3 V DC Interrupt signal
B1 +5V2 O 5 V DC 5 V DC power output to MPWB
B2 +5V2 O 5 V DC 5 V DC power output to MPWB
B3 GND - - Ground
B4 UDATAN I/O LVDS USB host data signal (-)
B5 UDATAP I/O LVDS USB host data signal (+)
B6 GND - - Ground
B7 FPRSTN I 0/3.3 V DC OPPWB reset signal
B8 P2C_PKEY O 0/3.3 V DC OK KEY:On/Off
B9 P2C_SDAT O 0/3.3 V DC The data signal between panel main
B10 SAMPLE2 I 0/3.3 V DC Sample / hold signal 2
B11 PDN O 0/3.3 V DC (pulse) Main scanning synchronizing signal
Connector Pin Signal I/O Voltage Description

Kyocera ECOSYS P4040dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	40 ppm
Printing colors	Black
Maximum duty cycle	150000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter XL24E, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	600 sheets
Total output capacity	500 sheets
Maximum input capacity	2600 sheets
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 297 mm
Custom media length	148 - 450 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	-
Mobile printing technologies	Apple AirPrint
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Processor model	465
Processor family	PowerPC
Noise level (idle)	30 dB
Maximum internal memory	1280 MB
Sound pressure level (printing)	50.4 dB
Sound pressure level (quiet mode)	49.6 dB
Display	LCD
Certification	TUV, GS, CE
Product color	Black, White
Display number of lines	5 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (standby)	14 W
Power consumption (printing)	586 W
Power consumption (PowerSave)	1.5 W
Sustainability certificates	ENERGY STAR
Mac operating systems supported	Mac OS X 10.5 Leopard
Other operating systems supported	Android, iOS

Weight and Dimensions

Depth	410 mm
Width	469 mm
Height	320 mm
