Kyocera ECOSYS P4040dn Service Manual

2P7/2R0/3PN
2-3-12
YC20
B12 VDATA1P I LVDS Video data 1 signal (+)
Connected to
the main
PWB
B13 VDATA1N I LVDS Video data 1 signal (-)
B14 PLGCLK I 0/3.3 V DC (pulse) PM clock signal
B15 E2C_SDAT O 0/3.3 V DC (pulse) Serial communication data output
B16 C2E_SCKN I 0/3.3 V DC (pulse) Serial communication clock
B17 E2C_SDIR O 0/3.3 V DC Communication direction change signal
B18 VSYNC O 0/3.3 V DC (pulse) Sub scanning synchronizing signal
B19 C2E_OFFRD
Y
I 0/3.3 V DC Off-mode notice signal
B20 C2E_INT I 0/3.3 V DC Interrupt signal
YC21
1 TH2 I Analog FUTH2 output signal
Connected to
the fuser
thermistor
connect
PWB
2 TH1 I Analog FUTH1output signal
3 GND - - Ground
4 REARFANN O 24 V DC REFM: On/Off
5 +24V4 O 24 V DC 24 V DC power output to FTHPWB
YC22
1 +24V5 O 24 V DC 24 V DC power output to PF
Connected to
the paper
feeder
2 OPSDO O 0/3.3 V DC (pulse) PF communication serial data signal
3 OPSDI I 0/3.3 V DC (pulse) PF communication serial data signal
4 OPCLK O 0/3.3 V DC (pulse) PF communication serial clock signal
5 OPRDYN I 0/3.3 V DC Option communication ready signal
6 +3.3V7 O 3.3 V DC 3.3 V DC power output to PF
7 GND - - Ground
8 OPSEL2 O 0/3.3 V DC PF select signal
9 OPSEL1 O 0/3.3 V DC PF select signal
10 OPSEL0 O 0/3.3 V DC PF select signal
11 OPPAUSEN O 0/3.3 V DC Paper stop signal
12 GND - - Ground
YC23
1 VBUS O 5 V DC 5 V DC power output to USB host
Connected to
the USB host
2 UDATAN I/O LVDS USB data signal (-)
3 UDATAP I/O LVDS USB data signal (+)
4 GND - - Ground
5 GND - - Ground
YC26
1 +3.3V13 O 3.3 V DC 3.3 V DC power output to ES
Connected to
the eject sen-
sor
2 GND - - Ground
3 EXITSENSN I 0/3.3 V DC ES: On/Off
Connector Pin Signal I/O Voltage Description

Kyocera ECOSYS P4040dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	40 ppm
Printing colors	Black
Maximum duty cycle	150000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter XL24E, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	600 sheets
Total output capacity	500 sheets
Maximum input capacity	2600 sheets
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 297 mm
Custom media length	148 - 450 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	-
Mobile printing technologies	Apple AirPrint
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Processor model	465
Processor family	PowerPC
Noise level (idle)	30 dB
Maximum internal memory	1280 MB
Sound pressure level (printing)	50.4 dB
Sound pressure level (quiet mode)	49.6 dB
Display	LCD
Certification	TUV, GS, CE
Product color	Black, White
Display number of lines	5 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (standby)	14 W
Power consumption (printing)	586 W
Power consumption (PowerSave)	1.5 W
Sustainability certificates	ENERGY STAR
Mac operating systems supported	Mac OS X 10.5 Leopard
Other operating systems supported	Android, iOS

Weight and Dimensions

Depth	410 mm
Width	469 mm
Height	320 mm
