Kyocera ECOSYS P4040dn - Page 38

2P7/2R0/3PN
1-2-11
1. Open the rear cover.
2. Remove the inlet cover.
3. Connect the USB interface cable to the
printer and PC.
Figure 1-2-17
4. Connect the network interface cable to
the printerand network.
Figure 1-2-18
5. Connect the power cord to the printer
and the wall outlet.
6. Refit the inlet cover.
7. Close the rear cover.
Figure 1-2-19
Connecting the cable
USB interface cable
Inlet cover
Network
interface cable
Power cord
Wall outlet
