Kyocera ECOSYS P6130cdn User Manual

7-3
Setup and Registration (System Menu) > System Menu
Menu Settings
This section explains the functions that can be configured in Menu. To configure the settings, select the item in System
Menu and select the setting item. For details on each function, see the table below.
Item Description Reference Page
Print Report Configure settings for printing reports and histories. page 7-4
Counter This counts the number of pages printed. page 2-29
Paper Settings Configure settings for paper. page 7-6
Print Settings Configure settings for printing. page 7-9
Message Language Select the language displayed on the message display. page 7-11
Buzzer Set options for buzzer sound during the machine operations. page 7-11
Error Handling Select whether to cancel or continue the job when error has occurred. page 7-11
ColorToner Empty Select whether printing is prohibited or the Print in Black and White
setting is used for printing once the color toner runs out.
page 7-12
TonerAlert Level Set the amount of remaining toner to notify the administrator when to
order a toner when the toner is running low.
page 7-12
SSD Format an optional SSD. page 7-12
SD Card Format an optional SD/SDHC memory card. page 7-12
Disp. Status/Log Set the display method of the Status/Log. page 7-13
Date Setting Configure settings related to the date and time. page 7-13
Timer Configure settings related to the time. page 7-14
RAM Disk Mode A RAM disk can be created and its size can be set. page 7-15
User/Job Account Configures settings related to machine management.
User Login:
Overview of User Login Administration (page 8-2)
Job Accounting:
Overview of Job Accounting (page 8-6)
—
Network Configures machine system settings. page 7-16
Optional Network Configure settings for the optional Network Interface Kit or Wireless
Network Interface Kit.
page 7-18
Security The security functions can be set up to protect printer operation and the
print data.
page 7-19
I/F Block This allows you to protect this machine by blocking the interface with
external devices such as USB hosts or optional interfaces.
page 7-21
Security Level The Security Level setting is primarily a menu option used by service
personnel for maintenance work. There is no need for customers to use
this menu.
—
Restart Printer Restart the CPU without turning the power switch off. Use this to deal with
any unstable operation by the machine. (Same as the computer restart.)
page 7-23
Data Security Configure settings for data stored in the machine's memory. page 7-22
Op Functions You can use the optional applications installed on this machine. page 7-23
Administrator The Administrator setting is a function that identifies a user who can use
the printer and manage other users.
page 7-23

Kyocera ECOSYS P6130cdn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	7 s
Time to first page (color, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	100000 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	600 sheets
Total output capacity	250 sheets
Maximum input capacity	2100 sheets
Total number of input trays	2
Maximum number of input trays	5
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	No
Mobile printing technologies	Apple AirPrint
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	3
Processor family	PowerPC
Noise level (idle)	38.6 dB
Maximum internal memory	2048 MB
Sound pressure level (printing)	49.2 dB
Sound pressure level (quiet mode)	46.3 dB
Display	LCD
Certification	TUV, GS, CE
Product color	Black, White
Display number of lines	2 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (standby)	56 W
Power consumption (printing)	479 W
Power consumption (PowerSave)	2 W
Sustainability certificates	ENERGY STAR
Mac operating systems supported	Mac OS X 10.5 Leopard
Other operating systems supported	Android, iOS

Weight and Dimensions

Depth	532 mm
Width	390 mm
Height	410 mm
