10-17
Appendix > Paper
Hagaki (Cardstock)
Before loading Hagaki (Cardstock) into the multi purpose tray, fan them and align the edges. If the Hagaki (Cardstock)
paper is curled, straighten it before loading. Printing onto curled Hagaki (Cardstock) may cause jams.
Use unfolded Oufuku hagaki (Return postcard) (available at post offices). Some Hagaki (Cardstock) may still have rough
edges developed by a paper cutter on the back side. Remove any such rough edges by placing the Hagaki (Cardstock)
on a flat surface and rubbing the edges gently a few times with a ruler.
Envelopes
Envelopes should be fed from the MP tray with the print-side up or the optional paper feeder with the print-side up.
Due to the structure of envelopes, printing evenly over the entire surface may not be possible in some cases. Thin
envelopes in particular may be wrinkled by the machine in some cases as they pass through. Before purchasing
envelopes in volume, try testing a sample to ensure the print quality.
Storing envelopes for a long period may cause them to become wrinkled. Thus, keep the package sealed until you are
ready to use them.
Keep the following points in mind.
Do not use envelopes with exposed adhesive. In addition, do not use the type of envelope in which the adhesive is
exposed after the top layer is peeled off. Serious damage may be caused if the paper covering the adhesive comes
off in the machine.
Do not use envelopes with certain special features. For example, do not use envelopes with a grommet for winding a
string to close the flap or envelopes with an open or film-covered window.
If paper jams occur, load fewer envelopes at once.
Thick Paper
Before loading thick paper in the multi purpose tray, fan it and align the edges. Some thick paper may still have rough
edges developed by a paper cutter on the back side. Remove any such rough edges just as with Hagaki (Cardstock) by
placing the paper on a flat surface and rubbing the edges gently a few times with a ruler. Printing onto paper with rough
edges may cause jams.
NOTE
Do not load paper above the load limits located on the paper width guide of the optional paper feeder.
NOTE
If the paper is not supplied correctly even after it is smoothed, load the paper in the multi purpose tray with the leading
edge raised a few millimeters.
Burrs
Burrs

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kyocera ECOSYS P6130cdn and is the answer not in the manual?

Kyocera ECOSYS P6130cdn Specifications

General IconGeneral
ColorYes
Print technologyLaser
Maximum resolution9600 x 600 DPI
Duplex printing modeAuto
Time to first page (black, normal)7 s
Time to first page (color, normal)8 s
Print speed (black, normal quality, A4/US Letter)30 ppm
Printing colorsBlack, Cyan, Magenta, Yellow
Maximum duty cycle100000 pages per month
Number of print cartridges4
Page description languagesMicrosoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input typeCassette, Paper tray
Total input capacity600 sheets
Total output capacity250 sheets
Maximum input capacity2100 sheets
Total number of input trays2
Maximum number of input trays5
Multi-Purpose tray input capacity100 sheets
Custom media width70 - 216 mm
Maximum print size216 x 356 mm
Custom media length148 - 356 mm
Paper tray media typesPlain paper
Paper tray media weight60 - 163 g/m²
Non-ISO print media sizesFolio (media size), Letter (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 220 g/m²
Wi-FiNo
Mobile printing technologiesApple AirPrint
Standard interfacesEthernet, USB 2.0
USB 2.0 ports quantity3
Processor familyPowerPC
Noise level (idle)38.6 dB
Maximum internal memory2048 MB
Sound pressure level (printing)49.2 dB
Sound pressure level (quiet mode)46.3 dB
DisplayLCD
CertificationTUV, GS, CE
Product colorBlack, White
Display number of lines2 lines
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (off)0.1 W
Power consumption (standby)56 W
Power consumption (printing)479 W
Power consumption (PowerSave)2 W
Sustainability certificatesENERGY STAR
Mac operating systems supportedMac OS X 10.5 Leopard
Other operating systems supportedAndroid, iOS
Weight and Dimensions IconWeight and Dimensions
Depth532 mm
Width390 mm
Height410 mm
