Kyocera ECOSYS P6130cdn User Manual

2-40
Installing and Setting up the Machine > Command Center RX
4
Configure the settings.
Enter "SMTP" and "E-mail Send Settings" items.
5
Click [Submit].
Setting Description
SMTP Set to send e-mail from the machine.
SMTP Protocol Displays the SMTP protocol settings. Check that "SMTP Protocol"
is set to [On]. If [Off] is set, click [Protocol] and set the SMTP
protocol to [On].
SMTP Server Name
*1
*1 Be sure to enter the items.
Enter the host name or IP address of the SMTP server.
SMTP Port Number Specify the port number to be used for SMTP. Use the SMTP
default port 25.
SMTP Server Timeout Set the amount of time to wait before time-out in seconds.
Authentication Protocol To use SMTP authentication, enter the user information for
authentication.
SMTP Security Set SMTP security.
Turn on "SMTP Security" in "SMTP (E-mail TX)" on the
[Protocol Settings] page.
Connection Test Tests to confirm that the settings are correct.
Domain Restriction To restrict the domains, click the [Domain List] and enter the
domain names of addresses to be allowed or rejected. Restriction
can also be specified by e-mail address.
POP3 POP3 Protocol You don't need to set the following items when you only enable the
function of sending e-mail from the machine. Set the following
items if you want to enable the function of receiving e-mail on the
machine.
Command Center RX User Guide
Check Interval
Run once now
Domain Restriction
POP3 User Settings
E-mail
Send
Settings
E-mail Size Limit Enter the maximum size of E-mail that can be sent in kilobytes.
When E-mail size is greater than this value, an error message
appears and E-mail sending is cancelled. Use this setting if you
have set E-mail Size Limit for SMTP server. If not, enter a value of
0 (zero) to enable E-mail sending regardless of the size limit.
Sender Address
*1
Specify the sender address for when the machine sends E-mails,
such as the machine administrator, so that a reply or non-delivery
report will go to a person rather than to the machine. The sender
address must be entered correctly for SMTP authentication. The
maximum length of the sender address is 128 characters.
Signature Enter the signature. The signature is free form text that will appear
at the end of the E-mail body. It is often used for further
identification of the machine. The maximum length of the
signature is 512 characters.
Function Defaults Change the function default settings in [Common/Job Default
Settings] page.

Kyocera ECOSYS P6130cdn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	7 s
Time to first page (color, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	100000 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	600 sheets
Total output capacity	250 sheets
Maximum input capacity	2100 sheets
Total number of input trays	2
Maximum number of input trays	5
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	No
Mobile printing technologies	Apple AirPrint
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	3
Processor family	PowerPC
Noise level (idle)	38.6 dB
Maximum internal memory	2048 MB
Sound pressure level (printing)	49.2 dB
Sound pressure level (quiet mode)	46.3 dB
Display	LCD
Certification	TUV, GS, CE
Product color	Black, White
Display number of lines	2 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (standby)	56 W
Power consumption (printing)	479 W
Power consumption (PowerSave)	2 W
Sustainability certificates	ENERGY STAR
Mac operating systems supported	Mac OS X 10.5 Leopard
Other operating systems supported	Android, iOS

Weight and Dimensions

Depth	532 mm
Width	390 mm
Height	410 mm
