56
5Click
Custom... . The Custom Paper Sizes dialog box appears.
6Click
Add... . The Add Paper Size dialog box appears. Enter a name for your custom paper
size in the Name field.
7 Enter the measurements in the
Height and Width boxes in millimeters or inches. (Units are
selected from the
User dialog box of the Device Settings tab in the Properties dialog
box.)
8 The following sizes are available for custom paper.
NOTE
The name can be up to 31 characters.
Size Cassette MP tray Duplexer unit
Minimum (A4 printers) 148 × 210 mm
(5.8 x 8.3 inches)
70 × 148 mm (Portrait) 148 × 216 mm
Largest (A4 printers) 216 × 356 mm
(8.5 x 14 inches)
216 × 356 mm (Portrait) 216 × 356 mm
Minimum (A3 printers) 148 × 210 mm
(5.8 x 8.3 inches)
70 × 148 mm 148 × 210 mm
Largest (A3 printers) 297 × 450 mm
(11.7 x 17.7 inches)
310 × 458 mm 297 × 431.8 mm
To Next Page
