Kyocera FS-1020D

2FM
2-4-1
Timing chart No. 1 Paper cassette feeding, A4/8
1
/2" × 11" paper, simplex printing
0 10
5
100
1310
800 1400
1500
200
4010 4310 7010
3800 4400
930 4040 4500
3283 5793 6283 8793
10083
10083
10083
8809
1744
8809
1500
45004242 7242
800
+570 V
0 V
-1800 V
2005
4414
4805
10083
7514
5005
4514
7414
Drum speed: 117.90 mm/s
Paper feeding speed: 197.00 mm/s
Printing speed: 20.00 ppm
15
MOTORN
(Main motor)
MHVDR
(Main charger)
THVDR/RTHVDR
(Transfer charger)
PFMDRN
(Cassette feed motor)
RESDRN
(Registration clutch)
OUTPEN
(Laser diode)
BIAS
(Developing bias)
ERASPW
(Eraser lamp)
PLGDRN
(Polygon motor)
RESIT
(Registration sensor)
EXITN
(Exit sensor)
