Kyocera FS-1020D

2FM
1-1-5
Cassette, MP tray
Optional paper feeder
Switchback and refeed (duplex printing)
Paper path
8
3
4
6
5
0 !7 21
9
1-1-3 Machine cross section
1 Cassette
2 Paper feed unit
3 MP tray
4 MP tray paper feed unit
5 Process unit
6 Toner container
Figure 1-1-2
7 Transfer section
8 Fuser unit
9 Face-down output tray
0 Switchback/conveying section
! Refeed unit
