Kyocera FS-1370DN Service Manual

2L0-1
1-3-13
Service items Description
No. Items Description
7
cont.
(b) Detail of paper source (Hexadecimal)
00: MP tray
01: Cassette 1 (Printer)
02: Cassette 2 (Paper feeder 1)
03: Cassette 3 (Paper feeder 2)
04 to 09: -
(c) Detail of paper size (Hexadecimal)
00: (indefinite)
01: Monarch
02: Business
03: International DL
04: International C5
05: Executive
06: Letter-R
86: Letter-E
07: Legal
08: A4R
88: A4E
09: B5R
89: B5E
0A: A3
0B: B4
0C: Ledger
0D: A5
0E: A6
0F: B6
10: Commercial #9
11: Commercial #6
12: ISO B5
13: Custom size
1E: C4
1F: Postcard
20: Reply-paid postcard
21: Oficio II
22: Special 1
23: Special 2
24: A3 wide
25: Ledger wide
26: Full bleed paper
(12 × 8)
27: 8K
28: 16K-R
A8: 16K-E
32: Statement-R
B2: Statement-E
33: Folio
34: Western type 2
35: Western type 4
(d) Detail of paper type (Hexadecimal)
01: Plain
02: Transparency
03: Preprint
04: Labels
05: Bond
06: Recycle
07: Vellum
08: Rough
09: Letter head
0A: Color
0B: Prepunched
0C: Envelope
0D: Cardstock
0E: Coated
0F: 2nd side
10: Media 16
11: High quality
15: Custom 1
16: Custom 2
17: Custom 3
18: Custom 4
19: Custom 5
1A: Custom 6
1B: Custom 7
1C: Custom 8
(e) Detail of paper exit location (Hexadecimal)
01: Face down tray (FU)
02 to 48: -
8 Service Call
(Self diagnostic
error) Log
# Count. Service Code
Remembers 1 to 8 of
occurrence of self diag-
nostics error. If the
occurrence of the previ-
ous diagnostics error is
less than 8, all of the
diagnostics errors are
logged.
The total page count at
the time of the self diag-
nostics error.
Self diagnostic error code
(See page 1-4-3)
Example
01.6000
01 means a self-diagnos-
tic error; 6000 means a
self diagnostic error code.

Kyocera FS-1370DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Memory type	DDR
Memory slots	1
Processor model	440F5
Processor family	PowerPC
Maximum internal memory	1152 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Sound pressure level (quiet mode)	49 dB
Total input capacity	300 sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Maximum number of input trays	4
Multi-Purpose tray input capacity	50 sheets
Mobile printing technologies	Not supported
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	11 W
Power consumption (printing)	554 W
Power consumption (PowerSave)	5.5 W
Printing colors	Black
Maximum duty cycle	50000 pages per month
Recommended duty cycle	2800 pages per month
Page description languages	Epson LQ, IBM ProPrinter, PCL 5e, PCL 6, PJL, PostScript 3
Display	LCD
Certification	GS, TUV, CE
Product color	Black, White
Custom media width	70 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Standard interfaces	Ethernet, USB 2.0
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows MultiPoint Server 2011, Windows SBS 2011 Essentials, Windows SBS 2011 Standard, Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	267 mm
