Kyocera FS-1370DN Service Manual

2L0
1-4-4
2000 Main motor error
The main motor ready input is not given
for 2 s during the main motor is ON.
Defective harness
between main
motor (CN1) and
control PWB
(YC305), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective drive
transmission sys-
tem of the main
motor.
Check if the rollers and gears rotate
smoothly. If not, grease the bushings and
gears. Check for broken gears and replace if
any.
Defective main
motor.
Replace the main motor (See page 1-5-28).
Defective control
PWB.
Replace the control PWB (See page 1-5-
19).
4000 Polygon motor (laser scanner unit)
error
The polygon motor ready input is not
given for 6 s during the polygon motor is
ON.
Defective harness
between polygon
motor and control
PWB (YC319), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective laser
scanner unit.
Replace the laser scanner unit (See page 1-
5-29).
Defective control
PWB.
Replace the control PWB (See page 1-5-
19).
4200 BD error (laser scanner unit) error Defective laser
scanner unit.
Replace the laser scanner unit (See page 1-
5-29).
Defective control
PWB.
Replace the control PWB (See page 1-5-
19).
6000 Broken fuser heater lamp wire
The fuser temperature does not rise after
the fuser heater lamp has been turned
on.
Poor contact in the
fuser thermistor
connector termi-
nals.
Reinsert the connector (See page 1-5-16).
Poor contact in the
fuser heater lamp
connector termi-
nals.
Reinsert the connector (See page 1-5-16).
Fuser thermistor
installed incor-
rectly.
Replace the fuser unit (See page 1-5-16).
Fuser thermal cut-
out triggered.
Replace the fuser unit (See page 1-5-16).
Fuser heater lamp
installed incor-
rectly.
Replace the fuser unit (See page 1-5-16).
Broken fuser
heater lamp wire.
Replace the fuser unit (See page 1-5-16).
6020 Abnormally high fuser thermistor
temperature
Fuser thermistor detects abnormally
temperature.
Shorted fuser
thermistor.
Replace the fuser unit (See page 1-5-16).
Defective control
PWB.
Replace the control PWB (See page 1-5-
19).
Code Contents
Remarks
Causes Check procedures/corrective measures

Kyocera FS-1370DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Memory type	DDR
Memory slots	1
Processor model	440F5
Processor family	PowerPC
Maximum internal memory	1152 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Sound pressure level (quiet mode)	49 dB
Total input capacity	300 sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Maximum number of input trays	4
Multi-Purpose tray input capacity	50 sheets
Mobile printing technologies	Not supported
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	11 W
Power consumption (printing)	554 W
Power consumption (PowerSave)	5.5 W
Printing colors	Black
Maximum duty cycle	50000 pages per month
Recommended duty cycle	2800 pages per month
Page description languages	Epson LQ, IBM ProPrinter, PCL 5e, PCL 6, PJL, PostScript 3
Display	LCD
Certification	GS, TUV, CE
Product color	Black, White
Custom media width	70 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Standard interfaces	Ethernet, USB 2.0
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows MultiPoint Server 2011, Windows SBS 2011 Essentials, Windows SBS 2011 Standard, Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	267 mm
