Kyocera FS-1370DN Service Manual

2L0
1-4-5
6030 Broken fuser thermistor wire
Input from fuser thermistor is 0 (A/D
value).
Poor contact in the
fuser thermistor
connector termi-
nals.
Reinsert the connector (See page 1-5-16).
Broken fuser
thermistor wire.
Replace the fuser unit (See page 1-5-16).
Fuser thermistor
installed incor-
rectly.
Replace the fuser unit (See page 1-5-16).
Fuser thermal cut-
out triggered.
Replace the fuser unit (See page 1-5-16).
Fuser heater lamp
installed incor-
rectly.
Replace the fuser unit (See page 1-5-16).
Broken fuser
heater lamp wire.
Replace the fuser unit (See page 1-5-16).
6400 Zero cross signal error
The zero cross signal does not reach the
control PWB for specified time.
Defective harness
between high volt-
age PWB (YC202)
and control PWB
(YC311), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective harness
between power
source PWB
(YC103) and high
voltage PWB
(YC201), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective power
source PWB.
Replace the power source PWB (See page
1-5-22).
Defective control
PWB.
Replace the control PWB (See page 1-5-
19).
F000 Control PWB - Operation panel PWB
communication error
Defective harness
between operation
panel PWB (YC1)
and control PWB
(YC7), or improper
connector inser-
tion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective opera-
tion panel PWB.
Replace the operation panel PWB.
Defective control
PWB.
Replace the control PWB (See page 1-5-
19).
F010 Control PWB checksum error Defective code
ROM (flash mem-
ory).
Turn the power switch off/on to restart the
printer. If the error is not resolved, replace
the control PWB (See page 1-5-19).
Defective control
PWB.
Replace the control PWB (See page 1-5-
19).
Code Contents
Remarks
Causes Check procedures/corrective measures

Kyocera FS-1370DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Memory type	DDR
Memory slots	1
Processor model	440F5
Processor family	PowerPC
Maximum internal memory	1152 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Sound pressure level (quiet mode)	49 dB
Total input capacity	300 sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Maximum number of input trays	4
Multi-Purpose tray input capacity	50 sheets
Mobile printing technologies	Not supported
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	11 W
Power consumption (printing)	554 W
Power consumption (PowerSave)	5.5 W
Printing colors	Black
Maximum duty cycle	50000 pages per month
Recommended duty cycle	2800 pages per month
Page description languages	Epson LQ, IBM ProPrinter, PCL 5e, PCL 6, PJL, PostScript 3
Display	LCD
Certification	GS, TUV, CE
Product color	Black, White
Custom media width	70 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Standard interfaces	Ethernet, USB 2.0
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows MultiPoint Server 2011, Windows SBS 2011 Essentials, Windows SBS 2011 Standard, Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
Sustainability certificates	ENERGY STAR
