Kyocera FS-1370DN Service Manual

2L0
1-4-6
F020 Control PWB RAM checksum error Defective main
memory (RAM) on
the control PWB.
Turn the power switch off/on to restart the
printer. If the error is not resolved, replace
control PWB (See page 1-5-19).
Defective
expanded memory
(DIMM).
Replace the expanded memory (DIMM)
(See page 1-2-4).
F030 Control PWB general failure Defective control
PWB.
Turn the power switch off/on to restart the
printer. If the error is not resolved, replace
control PWB (See page 1-5-19).
F040 Control PWB engine communication
error
Defective control
PWB.
Turn the power switch off/on to restart the
printer. If the error is not resolved, replace
control PWB (See page 1-5-19).
F050 Control PWB engine checksum error Some error may
have occurred
when downloading
the firmware of the
control PWB.
Download the firmware of the control PWB
again using the memory card (See page 1-
6-4).
Defective control
PWB.
Turn the power switch off/on to restart the
printer. If the error is not resolved, replace
control PWB (See page 1-5-19).
F186 Control PWB video data control error Defective control
PWB.
Turn the power switch off/on to restart the
printer. If the error is not resolved, replace
control PWB (See page 1-5-19).
Code Contents
Remarks
Causes Check procedures/corrective measures

Kyocera FS-1370DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Memory type	DDR
Memory slots	1
Processor model	440F5
Processor family	PowerPC
Maximum internal memory	1152 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Sound pressure level (quiet mode)	49 dB
Total input capacity	300 sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Maximum number of input trays	4
Multi-Purpose tray input capacity	50 sheets
Mobile printing technologies	Not supported
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	11 W
Power consumption (printing)	554 W
Power consumption (PowerSave)	5.5 W
Printing colors	Black
Maximum duty cycle	50000 pages per month
Recommended duty cycle	2800 pages per month
Page description languages	Epson LQ, IBM ProPrinter, PCL 5e, PCL 6, PJL, PostScript 3
Display	LCD
Certification	GS, TUV, CE
Product color	Black, White
Custom media width	70 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Standard interfaces	Ethernet, USB 2.0
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows MultiPoint Server 2011, Windows SBS 2011 Essentials, Windows SBS 2011 Standard, Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	267 mm
