1-7-1
FS-9120DN/9520DN
1-7-1 Downloading printer firmware for upgrade
The system (program) and engine firmware that are stored in a system DIMM PWB and a flash ROM on the engine
controller PWB are upgradable by downloading new firmware into these devices. Downloading can be made either by
directly sending the new firmware from PC via the parallel interface or using a memory card that contains the new
firmware.
The message data for the operator panel display is also downloadable so that a new message language is appended for
the operator panel. The message data should be downloaded directly from PC.
(1) Format for the firmware files
The file name for the firmware files is coded so that it implies the type, applicable product, and the version of the file.
Refer to the example below:
B10K15000.bcmp
Boot program is included.
ID code for Kyocera
ID code for Kyocera
EB10K0012.x
dm6602.dan
Machine code: FS-9120DN (B19)
FS-9520DN (B10)
Machine code: FS-9120DN (B19)
FS-9520DN (B10)
Message code: FS-9120DN (B19)
FS-9520DN (B10)
Language code dan: Danish
swe: Swedish
rus: Russian
pol: Polish
cze: Czech
hun: Hungarian
compression
Void
Version code: Version 150.00
Version code: Version 0012
Version code: Version 02
ID code for engine firmware
System firmware file name example
Engine firmware file name example
ID code for operator panel massage data
Operator panel message data file name example
Table 1-7-1
