1-7-3
FS-9120DN/9520DN
(3) Downloading firmware using the memory card
The procedure below provides how to download firmware from a memory card. A memory card can hold both the system
and the engine firmware together for downloading these firmware at a time.
1. Turn printer power on.
2. Insert the memory card into the printer's
memory card slot.
3. Press MENU key on the printer's operator
panel and format the memory card (1).
4. When formatting is complete, turn printer
power off.
5. Remove the formatted memory card from
the printer.
1. Insert the memory card to the PC's slot or to
the adaptor.
2. Copy the firmware file to download to the
root directory of the memory card.
3. Remove the memory card from the PC or
adaptor.
Formatting the memory card
Copying firmware files to the memory card
Message display
Operator panel keys
>Format ?
>Format
Processing
Ready
Ready
Memory Card >
Press the MENU key
Press the ENTER key
Press the key
Press the ENTER key
(The FORMAT INFORMATION is
printed automatically.)
Press the or key
Press the or key
1
Adapter
(Memory card reader/writer)
Memory card
To PC
Figure 1-7-3
Figure 1-7-4
Figure 1-7-5
Memory card
Memory card slot
To Next Page
