1-4-34
FS-9120DN/9520DN
7. Grasp the handle on the toner container and
insert the toner container along the rail of the
printer.
8. Hold the toner container by hands and fully
insert it into the printer.
9. Remove the old waste toner box as shown in
the figure.
Figure 1-4-8
Figure 1-4-9
Figure 1-4-10
Toner container
Waste toner box
