Kyocera FS-C2626MFP

2M8/2M9
1-4-32
(13) Offset occurs.
(14) Part of image is missing.
(15) Fusing is loose.
Print example Causes Check procedures/corrective measures
Defective drum surface charg-
ing.
Perform the drum surface refreshing (see page 1-3-72).
When the problem is not cleared, increase the surface
potential by performing the main charger adjustment (see
page 1-3-73).
Deformed or worn cleaning
blade in the drum unit.
Replace the drum unit (see page 1-5-21).
Defective transfer belt clean-
ing.
Replace the intermediate transfer unit (see page 1-5-22).
Defective fuser unit. Replace the fuser unit (see page 1-5-26).
Wrong types of paper. Check if the paper meets specifications. Replace paper.
Print example Causes Check procedures/corrective measures
Paper damp. Check the paper storage conditions.
Paper creased. Replace the paper.
Drum condensation. Perform the drum surface refreshing (see page 1-3-72).
Dirty or flawed drum. Perform the drum surface refreshing (see page 1-3-72).
Flawed drum. Replace the drum unit (see page 1-5-21).
Dirty transfer belt. Clean the transfer belt. Replace the intermediate transfer
unit if it is extremely dirty (see page 1-5-22).
Dirty transfer roller. Clean the transfer roller. Replace the transfer roller if it is
extremely dirty (see page 1-5-25).
Print example Causes Check procedures/corrective measures
Wrong types of paper. Check if the paper meets specifications, replace paper.
Flawed heat roller or press
roller.
Replace the fuser unit (see page 1-5-26).
