Kyocera FS-C2626MFP

2M8/2M9
1-5-62
1-5-12 Others
(1) Detaching and refitting the paper conveying unit
Procedure
1. Open the rear cover.
2. Remove left and right straps.
Figure 1-5-95
3. Remove the rear cover unit.
Figure 1-5-96
Rear cover
Strap
1
1
2
Rear cover unit
