Installation
5
On the Printer Settings page, you can assign a name for your printing system.
You can also choose to share this printer with others or set this printer as the
default printer. Make your selections, and then click Next.
6
On the Confirm Settings page, click Install if the settings are correct. Click
Back to correct the settings.
Note: If the Hardware Installation warning dialog box appears, click
Continue.
7
The Installation Completed page appears displaying the following driver
options.
Print a test page
This selection verifies a connection with the printer and creates a print out of
the installed driver components.
Enable Status Monitor
The Status Monitor displays system status messages on your computer
screen during printing tasks. The Status Monitor button appears on the
Advanced tab.
Show Quick Print Tab
This selection lets you define basic print options into group profiles that can
be accessed easily. The Show Quick Print tab option also appears in the
Administrator Settings in Device Settings.
Device Settings
Select the Device Settings check box to open Device Settings where you
can choose installed options for your printing system. (The Device Settings
check box appears only in Windows XP.)
When the installation completes successfully, click Finish to exit the installation
wizard and return to the Product Library CD menu.
A message may appear if there is a software installation failure.
Click Finish, and retry the installation. If the same message appears again,
contact your system administrator.
The installation of the printer is now complete. If prompted, restart your
computer.
Installing in Custom Mode with a USB Connection using Discover
This section describes the custom installation procedure of the driver software
in Windows operating systems using a USB connection. With Discover, all
devices available for the driver installation are found automatically. This is the
recommended Custom Mode USB installation method.
1
Ensure that your printer and computer are turned on and connected using a
USB cable.
Note: In Windows 7 and Windows Vista, a driver installation will be made from
the Microsoft Windows Update site if a certified driver is available and the
system is connected to the web. We recommend you continue with the steps to
install the KX Driver for an expanded feature set.
2
On the Installation Method page, select Custom Mode.
KX DRIVER
1-5

Table of Contents

Other manuals for Kyocera FS-C5150DN

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kyocera FS-C5150DN and is the answer not in the manual?

Kyocera FS-C5150DN Specifications

General IconGeneral
Wi-FiNo
Network readyYes
Print technologyLaser
Maximum resolution600 x 600 DPI
Print speed (black, normal quality, A4/US Letter)23 ppm
Maximum duty cycle50000 pages per month
Number of print cartridges4
Memory typeDDR
Memory slots1
Processor modelPowerPC 464
Maximum internal memory1280 MB
Sound power level (standby)50 dB
Display-
Total input capacity250 sheets
Total output capacity- sheets
Multi-Purpose tray input capacity50 sheets
Maximum print size216 x 356 mm
Paper tray media typesBond paper, Photo paper, Pre-Printed, Recycled paper
Non-ISO print media sizesLetter
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5, B6
Multi-purpose tray media typesBond paper, Letterhead, Recycled paper
Maximum ISO A-series paper sizeA4
Standard interfacesEthernet, USB 2.0
USB 2.0 ports quantity2
Mac operating systems supportedMac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Server operating systems supportedWindows Server 2003, Windows Server 2003 x64, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supportedWindows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (printing)- W
Weight and Dimensions IconWeight and Dimensions
Dimensions (WxDxH)391 x 523 x 371 mm
