Job
Warning: A print job can replace a job on the hard disk having the same User
name and Job name. To prevent this, select Use job name + date and time
under Overwrite job name.
Printing a Proof and Hold Job
Proof and hold lets you print one copy of a multicopy job to proof before
printing the remaining copies. The job is stored on the hard disk or RAM disk
memory until the printing system is turned off or the job is manually deleted.
1
In the Basic tab, select the number of copies to be printed.
2
Open the Job tab.
3
Click Job storage (e-MPS).
4
Click Proof and hold, and click OK.
Private Print
Private print jobs are saved on the hard disk or RAM disk for printing until a
four-digit access code is entered. When the hard disk reaches maximum
capacity and a new job is sent to be stored, the oldest stored job is replaced by
the new job. Private print jobs are deleted when the printing system is reset or
turned off. If you do not want the job deleted, select the Job storage feature.
When sending a sensitive document to the printing system, a user must type a
four-digit access code, which is attached to the print job along with the job name
and user name. The job is not printed until a user enters the access code at the
printing system’s operation panel. After the job is printed, it is removed from
printing system memory.
The number of Private print jobs that can be stored is limited only by the
storage capacity of the hard disk. You can manually delete a job at the
operation panel.
Warning: A print job can replace a job on the hard disk having the same user
name and job name. To prevent this, select Use job name + date and time
under Overwrite job name.
Storing a Private Print Job
Private print lets you store a document temporarily in printing system memory
without printing, and protect it with an Access code. The job is stored on the
hard disk until it is printed or manually deleted. The job is stored in RAM disk
memory until it is printed or the printing system is turned off.
1
In the Job tab, select Job storage (e-MPS).
2
Select Private print.
3
In the Access code box, type four numbers if you want to restrict access to
your document.
4
Click OK.
KX DRIVER
8-4

Table of Contents

Other manuals for Kyocera FS-C5150DN

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kyocera FS-C5150DN and is the answer not in the manual?

Kyocera FS-C5150DN Specifications

General IconGeneral
Wi-FiNo
Network readyYes
Print technologyLaser
Maximum resolution600 x 600 DPI
Print speed (black, normal quality, A4/US Letter)23 ppm
Maximum duty cycle50000 pages per month
Number of print cartridges4
Memory typeDDR
Memory slots1
Processor modelPowerPC 464
Maximum internal memory1280 MB
Sound power level (standby)50 dB
Display-
Total input capacity250 sheets
Total output capacity- sheets
Multi-Purpose tray input capacity50 sheets
Maximum print size216 x 356 mm
Paper tray media typesBond paper, Photo paper, Pre-Printed, Recycled paper
Non-ISO print media sizesLetter
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5, B6
Multi-purpose tray media typesBond paper, Letterhead, Recycled paper
Maximum ISO A-series paper sizeA4
Standard interfacesEthernet, USB 2.0
USB 2.0 ports quantity2
Mac operating systems supportedMac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Server operating systems supportedWindows Server 2003, Windows Server 2003 x64, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supportedWindows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (printing)- W
Weight and Dimensions IconWeight and Dimensions
Dimensions (WxDxH)391 x 523 x 371 mm
