Kyocera FS-C5150DN Service Manual

2KT/2KV
1-3-18
Service items Description
No. Items Description
(7)
cont.
Paper Jam
Log
1620: PF feed sensor 2 is turned ON
1820: PF feed sensor 3 is turned ON
4002: Registration sensor does not turn ON (Paper feeder 1)
4003: Registration sensor does not turn ON (Paper feeder 2)
4009: Registration sensor does not turn ON (MP tray)
4012: Registration sensor does not turn OFF (Paper feeder 1)
4013: Registration sensor does not turn OFF (Paper feeder 2)
4014: Registration sensor does not turn OFF (Paper feeder 3)
4019: Registration sensor does not turn OFF (MP tray)
4020: Registration sensor is turned ON
4201: Eject sensor does not turn ON (Cassette)
4202: Eject sensor does not turn ON (Paper feeder 1)
4203: Eject sensor does not turn ON (Paper feeder 2)
4204: Eject sensor does not turn ON (Paper feeder 3)
4208: Eject sensor does not turn ON (Duplex)
4209: Eject sensor does not turn ON (MP tray)
4211: Eject sensor does not turn OFF (Cassette)
4212: Eject sensor does not turn OFF (Paper feeder 1)
4213: Eject sensor does not turn OFF (Paper feeder 2)
4214: Eject sensor does not turn OFF (Paper feeder 3)
4218: Eject sensor does not turn OFF (Duplex)
4219: Eject sensor does not turn OFF (MP tray)
4220: Eject sensor is turned ON
(b) Detail of paper source (Hexadecimal)
00: MP tray
01: Cassette 1
02: Cassette 2 (paper feeder 1)
03: Cassette 3 (paper feeder 2)
04: Cassette 4 (paper feeder 3)
05 to 09: Reserved
(c) Detail of paper size (Hexadecimal)
00: (Not specified)
01: Monarch
02: Business
03: International DL
04: International C5
05: Executive
06: Letter-R
86: Letter-E
07: Legal
08: A4R
88: A4E
09: B5R
89: B5E
0A: A3
0B: B4
0C: Ledger
0D: A5R
0E: A6
0F: B6
10: Commercial #9
11: Commercial #6
12: ISO B5
13: Custom size
1E: C4
1F: Postcard
20: Reply-paid post-
card
21: Oficio II
22: Special 1
23: Special 2
24: A3 wide
25: Ledger wide
26: Full bleed paper
(12 x 8)
27: 8K
28: 16K-R
A8: 16K-E
32: Statement-R
B2: Statement-E
33: Folio
34: Western type 2
35: Western type 4
