Kyocera FS-C5150DN Service Manual

2KT/2KV
1-4-40
1-4-5 Mechanical problems
If the part causing the problem was not supplied, use the unit including the part for replacement.
Problem Causes/check procedures Corrective measures
(1)
No primary paper
feed.
Check if the surfaces of the following roll-
ers are dirty with paper powder.
Pickup roller
Paper feed roller
MP paper feed roller
Clean with isopropyl alcohol.
Check if the following rollers is deformed.
Pickup roller
Paper feed roller
MP paper feed roller
Check visually and replace any
deformed (see page 1-5-14, 1-5-16).
Defective paper feed clutch installation. Check visually and remedy if necessary.
(2)
No secondary paper
feed.
Check if the surfaces of the following roll-
ers are dirty with paper powder.
Front registration roller
Rear registration roller
Clean with isopropyl alcohol.
Defective registration clutch installation. Check visually and remedy if necessary.
(3)
Skewed paper feed.
Paper width guide in a cassette installed
incorrectly.
Check the paper width guide visually
and remedy or replace if necessary.
(4)
Multiple sheets of
paper are fed.
Check if the paper is excessively curled. Change the paper.
Paper is loaded incorrectly. Load the paper correctly.
Check if the retard roller is worn. Replace the retard roller if it is worn
(see page 1-5-12).
(5)
Paper jams.
Check if the paper is excessively curled. Change the paper.
Check if the contact between the front
and rear registration rollers is correct.
Check visually and remedy if necessary.
Check if the heat roller or press roller is
extremely dirty or deformed.
Check visually and replace the fuser
unit (see page 1-5-25).
(6)
Toner drops on the
paper conveying path.
Check if the drum unit or developing unit
is extremely dirty.
Clean the drum unit or developing unit.
(7)
Abnormal noise is
heard.
Check if the rollers, pulleys and gears
operate smoothly.
Grease the bushes and gears.
Check if the following clutches are
installed correctly.
Paper feed clutch
MP feed clutch
Registration clutch
Middle clutch
Check visually and remedy if necessary.

Kyocera FS-C5150DN Specifications

General

Wi-Fi	No
Network ready	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	23 ppm
Maximum duty cycle	50000 pages per month
Number of print cartridges	4
Memory type	DDR
Memory slots	1
Processor model	PowerPC 464
Maximum internal memory	1280 MB
Sound power level (standby)	50 dB
Display	-
Total input capacity	250 sheets
Total output capacity	- sheets
Multi-Purpose tray input capacity	50 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Photo paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Letterhead, Recycled paper
Maximum ISO A-series paper size	A4
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	2
Mac operating systems supported	Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (printing)	- W

Weight and Dimensions

Dimensions (WxDxH)	391 x 523 x 371 mm
