Kyocera FS-C5150DN

2KT/2KV
1-4-2
(2) Paper misfeed detection condition
Figure 1-4-2 Paper jam location
Machine
B
C
D
E
A
F
G
H
1
3
2
4
5
6
Sensors
Registration sensor
MP feed sensor
Eject sensor
PF feed sensor 1
PF feed sensor 2
PF feed sensor 3
1
2
3
4
5
6
Paper jam location
Cassette 1
MP tray
Machine inside
Fuser/Eject sections
Duplex section
Cassette 2
Cassette 3
Cassette 4
A
B
C
D
E
F
G
H
Paper feeder 1
Paper feeder 2
Paper feeder 3
