Kyocera FS-C5150DN

2KT/2KV
1-2-13
1-2-5 Installing the network interface card (option)
Procedure
1. Turn off the main power switch.
2. Remove the IF cover.
3. Remove two pins and then remove the
slot cover.
Figure 1-2-20
4. Insert the network interface card into
the interface slot.
5. Secure the network interface card by
using two pins.
Figure 1-2-21
Pin
Pin
IF cover
Slot cover
Pin
Pin
Network interface card
Interface slot
