Kyocera FS-C5150DN Service Manual

2KT/2KV
1-3-17
Service items Description
No. Items Description
(5) Operation panel mask version
(6) Machine serial number
(7) Paper Jam
Log
# Count. Event
Remembers 1 to 16 of
occurrence. If the occur-
rence of the previous
paper jam is less than
16, all of the paper jams
are logged. When the
occurrence excesseds
16, the oldest occur-
rence is removed.
The total page count
at the time of the
paper jam.
Log code (hexadeci-
mal, 5 categories)
(a) Cause of a paper
jam
(b) Paper source
(c) Paper size
(d) Paper type
(e) Paper eject
(a) Cause of paper jam (Hexadecimal)
Refer to P.1-4-1 for paper jem location
0100: Controller sequence error
0105: Registration sensor not detected
0106: Controller sequence error
0110: Top tray open
0111: Rear cover open
0112: Front cover open
0113: MP tray open
0120: Controller sequence error
0121: Controller sequence error
0211: Rear cover open (paper feeder 1)
0212: Rear cover open (paper feeder 2)
0213: Rear cover open (paper feeder 3)
0501: No paper feed from cassette 1
0502: No paper feed from cassette 2
0503: No paper feed from cassette 3
0504: No paper feed from cassette 4
0508: No paper feed from duplex section
0509: No paper feed from MP tray
0511: Multiple sheets in cassette 1
0512: Multiple sheets in cassette 2
0513: Multiple sheets in cassette 3
0514: Multiple sheets in cassette 4
0518: Multiple sheets in duplex section
0519: Multiple sheets in MP tray
1020: MP feed sensor is turned ON
1403: PF feed sensor 1 does not turn ON (Paper feeder 2)
1404: PF feed sensor 1 does not turn ON (Paper feeder 3)
1413: PF feed sensor 1 does not turn OFF (Paper feeder 2)
1414: PF feed sensor 1 does not turn OFF (Paper feeder 3)
1420: PF feed sensor 1 is turned ON
1604: PF feed sensor 2 does not turn ON (Paper feeder 3)
1614: PF feed sensor 2 does not turn OFF (Paper feeder 3)

Kyocera FS-C5150DN Specifications

General

Wi-Fi	No
Network ready	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	23 ppm
Maximum duty cycle	50000 pages per month
Number of print cartridges	4
Memory type	DDR
Memory slots	1
Processor model	PowerPC 464
Maximum internal memory	1280 MB
Sound power level (standby)	50 dB
Display	-
Total input capacity	250 sheets
Total output capacity	- sheets
Multi-Purpose tray input capacity	50 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Photo paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Letterhead, Recycled paper
Maximum ISO A-series paper size	A4
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	2
Mac operating systems supported	Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (printing)	- W

Weight and Dimensions

Dimensions (WxDxH)	391 x 523 x 371 mm
