2JL/2JJ/2JG/2JD-1
2-1-12
2-1-5 Transfer/separation section
(1) Primary transfer section
There are four transfer (TC) rollers opposed to each color drum inside of transfer (TC) belt, toner on the drum is trans-
ferred to transfer belt by impressed bias voltage (minus). Remaining toner on the transfer (TC) belt is cleaned by fur brush.
Figure 2-1-15 Primary transfer section
Figure 2-1-16 Primary transfer section block diagram
(1) TC frame
(2) Drive roller
(3) Backup roller
(4) Transfer (TC) rollers
(5) Tension roller
(6) Idle roller
(7) Transfer (TC) belt
(8) ICL blade
(9) ICL screw
(10) ICL frame
(11) Sweep roller
(12) Fur brush
(13) ICL top cover
BLT FAN2
YC28-B2
YC9-7
YC9-6
YC9-5
YC9-4
YC9-3
YC9-2
YC9-1
YC28-B6
BLT SET
TRBSDS
TRBSDPWB
EPWB
MTRM
Transfer (TC) belt
TRDS
TRFM2
TRFM1
YC5-1
YC3-4
YC3-3
YC3-2
YC3-1
YC5-2
YC5-3
YC5-4
BLT_MOT_BN
BLT_MOT_BP
BLT_MOT_AN
BLT_MOT_AP
MRYPWB
BLT_MOT_MODE
BLT_MOT_CLK
BLT_MOT_PD
BLT_MOT_DR
YC23-B7
YC23-B8
YC23-B9
YC23-B10
T1_CONT3
T1_CONT4
FB_CONT
T1_INV_REM
Transfer belt
cleaning bias
FB_REM
T1_CONT1
T1_CONT2
THVPWB1
Transfer (TC) roller x 4
Fur brush
BLT FAN1
YC28-A2
YC28-B4
BLT SPEED
To Next Page
