2JL/2JJ/2JG/2JD-1
2-4-2
Maintenance kits
Maintenance part name
Part No.
Alternative
part No.
Fig.
No.
Ref.
No.
Name used in service manual Name used in parts list
<For 120 V specifications>
Maintenance kit A
(25/25, 32/25, 32/32 ppm models)
MK-825/MAINTENANCE KIT
(25/25, 32/25, 32/32 ppm models)
1702FZ7US0 072FZ7US 31 -
Developing unit BK DLP K ASS'Y - - - -
Fuser unit FUSER 120 ASS'Y - - - -
Transfer roller ROLLER TRANSFER - - - -
Drum unit DRUM ASS'Y - - - -
Transfer belt unit
PARTS TRANSFER BELT ASS'Y
----
Maintenance kit A
(40/35 ppm model)
MK-826A/MAINTENANCE KIT
(40/35 ppm model)
1702JF7US0 072JF7US 31 -
Developing unit BK DLP K ASS'Y - - - -
Fuser unit FUSER 120 ASS'Y - - - -
Transfer roller ROLLER TRANSFER - - - -
Drum unit DRUM ASS'Y - - - -
Transfer belt unit
PARTS TRANSFER BELT ASS'Y
----
<For 220 - 240 V specifications>
Maintenance kit A
(25/25, 32/25, 32/32 ppm models)
MK-825(NL)/MAINTENANCE KIT
(25/25, 32/25, 32/32 ppm models)
1702FZ8NL0 072FZ8NL 31 -
Developing unit BK DLP K ASS'Y - - - -
Fuser unit FUSER 200 ASS'Y - - - -
Transfer roller ROLLER TRANSFER - - - -
Drum unit DRUM ASS'Y - - - -
Transfer belt unit
PARTS TRANSFER BELT ASS'Y
----
Maintenance kit A
(40/35 ppm model)
MK-826A/MAINTENANCE KIT
(40/35 ppm model)
1702JF8NL0 072JF8NL 31 -
Developing unit BK DLP K ASS'Y - - - -
Fuser unit FUSER 200 ASS'Y - - - -
Transfer roller ROLLER TRANSFER - - - -
Drum unit DRUM ASS'Y - - - -
Transfer belt unit
PARTS TRANSFER BELT ASS'Y
----
<For 110 V specifications>
Maintenance kit A MK-825A(TW)/MAINTENANCE KIT 1702FZTTW0 72FZTTW 31 -
Developing unit BK DLP K ASS'Y - - - -
Fuser unit FUSER 110 ASS'Y - - - -
Transfer roller ROLLER TRANSFER - - - -
Drum unit DRUM ASS'Y - - - -
Transfer belt unit
PARTS TRANSFER BELT ASS'Y
----
Maintenance kit B MK-825B 1702FZ0UN0 072FZ0UN 31 -
Developing unit Y DLP Y ASS'Y - - - -
Developing unit C DLP C ASS'Y - - - -
Developing unit M DLP M ASS'Y - - - -
To Next Page
