2JL/2JJ/2JG/2JD
2-4-3
Periodic maintenance procedures
Section
Maintenance
part/location
Method
Maintenance
cycle
Points and cautions Page
Test copy
and test print
Perform at the maxi-
mum copy size
Test copy Every service
Section
Maintenance
part/location
Method
Maintenance
cycle
Points and cautions Page
Paper feed
section
Paper feed pulley Check or
replace
Every service Clean with alcohol or a dry cloth.
Replace after feeding 150,000
sheets.
P.1-5-2
Separation pulley Check or
replace
Every service Clean with alcohol or a dry cloth.
Replace after feeding 150,000
sheets.
P.1-5-2
Forwarding pulley Check or
replace
Every service Clean with alcohol or a dry cloth.
Replace after feeding 150,000
sheets.
P.1-5-2
MP paper feed pulley Check or
replace
Every service Clean with alcohol or a dry cloth.
Replace after feeding 150,000
sheets.
P.1-5-6
MP separation pulley Check or
replace
Every service Clean with alcohol or a dry cloth.
Replace after feeding 150,000
sheets.
P.1-5-6
MP forwarding pulley Check or
replace
Every service Clean with alcohol or a dry cloth.
Replace after feeding 150,000
sheets.
P.1-5-6
Registration left roller Clean Every service Clean with alcohol or a dry cloth.
Registration right roller Clean Every service Clean with alcohol or a dry cloth.
Bypass A roller Clean Every service Clean with alcohol or a dry cloth.
Bypass B roller Clean Every service Clean with alcohol or a dry cloth.
MP middle roller Clean Every service Clean with alcohol or a dry cloth.
Replace after feeding 150,000
sheets.
MP bypass pulley Clean Every service Clean with alcohol or a dry cloth.
Middle R roller Clean Every service Clean with alcohol or a dry cloth.
Feed low roller Clean Every service Clean with alcohol or a dry cloth.
Rollers and pulleys Clean Every service Clean with alcohol or a dry cloth.
Clutches Check Every service Check state of paper feed
Guides Clean Every 300,000
counts
Clean with alcohol or a dry cloth.
To Next Page
