WATER AND DRAINAGE PLUMBING_______________________
Your KZ recreational vehicle has a complete water system, to carry
fresh water, as well as holding tanks for used water. Each group
has its own explanation along with its own operation.
FRESH WATER SYSTEM_________________________________
Tanks
Water containers are installed inside of the coach under the bed,
dinette or sofa. On some models these containers are installed
under the coach between frame members and protected with a
cover.
Each storage tank has an over flow line. DO NOT install a shut-off
valve at lower end of line. If unit had a shut-off valve, and the valve
is closed when filling the tank, the tank would split open.
Filling Fresh Water System
To place water in to your coach fresh water system, use one of the
following methods. Different fresh water entry’s are used depending
on model and floor plan.
A. City Water Fill See Figure 1
1. Water is received into the system through
a direct hookup, referred to as “city water
fill”. Attach a hose to the hook up and
supply line. Open the faucet from the
supply line. Enter the unit, and open any
faucet, to allow air to escape, as there
may be some air pockets.
2. You have the option to use direct water
from your city water hookup, or water from
your fresh water tank.
3. See figure 2, ( following page ) which some units use,
showing the water valve control board, with usage
instructions, for the water system. This board is located
inside a storage compartment door.
Figure 1
