King Slide Cable Sys
In a framework attached to the rear wall are a series of pulleys,
cables, and brackets pre-assembled and not visible.
Cables (8) are attached to brackets mounted, one in each corner
of slide out leading to adjustable brackets inside of the coach,
under a cover at floor level, for adjustment needs to seal in or out
position.
Adjustment bracket is attached to a chain , driven by a 12 volt
D.C. motor attached to a gear box. Any required adjustment
needs are to be performed by a selling or servicing dealer.
Electrical system is protected by a 30 amp breaker located in 12
volt fuse panel in the load center.
For 12 volt light, you need to plug power into wall socket on rear
wall above slide out. DO NOT forget to unplug light before
moving slide in for travel, damage to wiring will occur.
Manually Moving The ROOM
Locate the flexible shaft in your owners manual. Attach flexible
shaft to the 1/4” hex fitting on the end of the motor. Attach 1/4”
socket and ratchet to the other end, and turn in the proper
direction to move the room. If cables tighten, and motor shaft is
difficult to turn, reverse the direction. Over torquing can happen,
resulting in severe damage.
