53
3. Open faucet valves, and adjust to
desired temperature.
4. To end water usage, close faucet
valves and disconnect coil hose.
Outside shower has head and hose
already installed.
Fresh Water Line
Two lines, generally red for hot and blue for cold, transport water
through out the coach. Valves to direct water flow are near the city
water fill or pump area. Connector elbows and tees are plastic or
copper, and are held together with compression rings for no
leakage.
Low Point Drains
Low point drains are placed on recreational vehicles to drain water
lines, tanks, and water heater to prepare coach for winterization and
sanitizing systems. Valves may plastic or brass.
Fresh water supply tanks will have their own separate drains under
the floor and/or frame, with a valve to be opened to drain, over flow
drain line may be close by.
Plumbing lines also have Low Point drains located in various areas.
You may find them (2) for hot and cold coming out of storage areas,
outer metal skirt, through underbelly covers, control centers, etc.
Water should always drain out to the ground, not into underbelly
cover.
POTABLE WATER ONLY. SANITIZE, FLUSH AND DRAIN BE-
FORE USING. SEE INSTRUCTION MANUAL. FAILURE TO
COMPLY COULD RESULT IN DEATH OR SERIOUS INJURY.
DANGE R
!
