The following generic drawing shows the circuit breaker alignment
with number one being the main breaker on all floor plans.
Depending on the size, floor plan and options of your coach, circuit
three through six will vary and possibly not all circuits will be used.
Number two is generally the 20 amp air conditioner circuit.
An owner must realize and understand that a coach has a total of 30
amp service available to be used. Conserving and choosing which
appliance has priority in consumption needs to be part of the
planning.
Don’t forget loose items such as toasters, electric skillets, and coffee
pots also consume power. Include these also in your planning. 50
amp service provides another option.
50 Amp (Optional on some units)
On some larger coaches with more appliances that will require more
120-volt AC power are desired by owners. Availability of 50 amp
service is the best method providing you have 50 amps of incoming
power, if this option is available on your unit.
NEVER, under any circumstances, remove a grounding pin in any cord or
plug. It may mean the difference between LIFE OR DEATH.
