44
Slide-Outs
With many models of trailers, KZRV builds numerous slide out
systems as listed on following page, followed by descriptions.
Several different vendors supply components, loose and/or
attached to the frames.
1. Below frame system—All metal components are external,
located under floor and in frame, inside of enclosed
underbelly cover except rams moving in and out.
2. Above floor system—All components are inside and above
floor, to be found under dinette or sofa slide out.
3. Cable system—Used on all rear slide outs. All but 4 short
sections of system are enclosed inside of rear wall assembly,
2 at the top, and 2 at the bottom of slide.
Before operating the power slide-out system in your coach, read
and become familiar with these instructions, along with
components and operation methods. Most of these components
are inside of the enclosed underbelly cover and can’t be seen.
Power For Operation
All power slide systems operate on 12 volt DC power provided by
a fully charged auxiliary battery and converter. Thru a 12 volt
distribution load center breakers are provided for each slide. For
best performance, have 120 volt AC power attached to your
coach, feeding the distribution load center. Tow vehicle 12V
power may also be used as required.
A automatic reset breaker is located in the distribution box feeding
the operation switch to the motor.
Supplement your battery by either one of two choices
1. Hook up a 120 volt AC power cord to recreational vehicle for
The power supply should be turned OFF when connecting/disconnecting cables to
power supply and antenna, but should be turned ON when testing for voltage.
CAUTION
!
